Product Summary

The OPA2344UA rail-to-rail CMOS operational amplifier is designed for precision, lowpower,
miniature applications. The OPA2344UA is unity gain stable, while the OPA345 is optimized for gains greater than or equal to five, and has a gain-bandwidth product of 3MHz. The device is optimized to operate on a single supply from 2.5V and up to 5.5V with an input common-mode voltage range that extends 300mV beyond the supplies. Quiescent current of the OPA2344UA is only 250mA (max).

Parametrics

OPA2344UA absolute maximum ratings: (1)Supply Voltage, V+ to V-: 7.5V; (2)Signal Input Terminals, Voltage: (V–) –0.5V to (V+) +0.5V; Current: 10mA; (3)Output Short-Circuit: Continuous; (4)Operating Temperature: –55℃ to +125℃; (5)Storage Temperature: –65℃ to +150℃; (6)Junction Temperature: 150℃; (7)Lead Temperature (soldering, 10s): 300℃; (8)ESD Tolerance (Human Body Model): 4000V.

Features

OPA2344UA features: (1)rail-to-rail input; (2)rail-to-rail output (within 1mV); (3)low quiescent current: 150mA typ; (4)microsize packages: SOT23-5, MSOP-8, TSSOP-14; (5)gain-bandwidth: OPA344: 1MHz, G≥1, OPA345: 3MHz, G ≥ 5; (6)slew rate: OPA344: 0.8V/ms; OPA345: 2V/ms; (7)thd + noise: 0.006%.

Diagrams

OPA2344UA package

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
OPA2344UA
OPA2344UA
Texas Instruments
Operational Amplifiers - Op Amps Lo Pwr Single-Sply
Data Sheet
0-1: $1.40
1-25: $1.29
25-100: $1.01
100-250: $0.95
OPA2344UA/2K5
OPA2344UA/2K5
Texas Instruments
Operational Amplifiers - Op Amps Lo Pwr Single-Sply
Data Sheet
0-1790: $0.60
1790-2000: $0.57
2000-2500: $0.57
2500-5000: $0.53
OPA2344UAG4
OPA2344UAG4
Texas Instruments
Operational Amplifiers - Op Amps Lo Pwr Single-Sply
Data Sheet
0-1: $1.45
1-25: $1.16
25-100: $1.06
100-250: $0.95
OPA2344UA/2K5G4
OPA2344UA/2K5G4
Texas Instruments
Operational Amplifiers - Op Amps Lo Pwr Single-Sply
Data Sheet
0-1790: $0.60
1790-2000: $0.57
2000-2500: $0.57
2500-5000: $0.55
