ADS8344E

8-channel, 16-bit, sampling Analog-to-Digital converter, 20-QSOP, –0.3V to +6V, 100kHz, serial interface

Rated 5 Rating 5 | reviews | Write a review

Price:: US $7.50~8.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $7.50~8.00

PartNumber:: ADS8344E

Brand:: Texas Instruments - TI | Pack: DIP | D/C: 10+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. jenny's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2011-09-20

From Other Seller

Part Number:ADS8344E
US $7.50 - 8.00
CM300DY-12NF

US $63.00 - 80.00 / Piece
(0) Remove
STK795-810

US $12.00 - 16.00 / Piece
(0) Remove
Quantity:

piece

Product Summary

The ADS8344E is an 8-channel, 16-bit, sampling Analog-to-Digital (A/D) converter with a synchronous serial interface. Typical power dissipation is 10mW at a 100kHz throughput rate and a +5V supply. The reference voltage (VREF) can be varied between 500mV and VCC, providing a corresponding input voltage range of 0V to VREF. The ADS8344E includes a shutdown mode that reduces power dissipation to under 15μW. The ADS8344E is tested down to 2.7V operation. The applications of the ADS8344E include data acquisition, test and measurement equipment, industrial process control, personal digital assistants and battery-powered systems.

Parametrics

ADS8344E absolute maximum ratings: (1)+VCC to GND: –0.3V to +6V; (2)Analog Inputs to GND: –0.3V to +VCC + 0.3V; (3)Digital Inputs to GND: –0.3V to +6V; (4)Power Dissipation: 250mW; (5)Maximum Junction Temperature: +150℃; (6)Operating Temperature Range:–40 to +85℃; (7)storage temperature range: –65 to +150℃; (8)Lead Temperature (soldering, 10s): +300℃.

Features

ADS8344E features: (1)pin for pin with ADS7844; (2)single supply: 2.7V to 5V; (3)8-channel single-ended or 4-channel differential input; (4)up to 100kHz conversion rate; (5)84dB sinad; (6)serial interface; (7)QSOP-20 AND SSOP-20 packages.
