Product Summary

The DAC8534IPWR is a quad channel, 16-bit Digital-to-Analog Converter (DAC) offering low-power operation and a flexible serial host interface. Each on-chip precision output amplifier allows rail-to-rail output swing to be achieved over the supply range of 2.7V to 5.5V. The DAC8534IPWR supports a standard 3-wire serial interface capable of operating with input data clock frequencies up to 30MHz for IOVDD = 5V. The applications of the DAC8534IPWR inlcude portable instrumentation, closed-loop servo-control, process control, data acquisition systems, programmable attenuation and pc peripherals.

Parametrics

DAC8534IPWR absolute maximum ratings: (1)AVDD to GND: –0.3V to +6V; (2)Digital Input Voltage to GND: –0.3V to +AVDD + 0.3V; (3)VOUTA to VOUTD to GND: –0.3V to + AVDD + 0.3V; (4)Operating Temperature Range: –40℃ to +105℃; (5)Storage Temperature Range: –65℃ to +150℃; (6)Junction Temperature Range (TJ max): +150℃; (7)Power Dissipation: (TJ max – TA)/θJA; (8)θJA, Thermal Impedance: 118℃/W; (9)θJC, Thermal Impedance: 29℃/W; (10)Lead Temperature, Soldering: Vapor Phase (60s): +215℃; Infrared (15s): +220℃.

Features

DAC8534IPWR features: (1)power supply: +2.7V to +5.5V; (2)micropower operation: 950μA at 5V; (3)16-bit monotonic over temperature; (4)settling time: 10μs to ±0.003% FSR; (5)ultra-low AC crosstalk: –100dB typ; (6)power-on reset to zero-scale; (7)on-chip output buffer amplifier with rail-to-rail operation; (8)double buffered input architecture; (9)simultaneous or sequential output update and power-down; (10)16 channel broadcast capability; (11)schmitt-triggered inputs; (12)TSSOP-16 package.

Diagrams

DAC8534IPWR Architecture

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
DAC8534IPWR
DAC8534IPWR
Texas Instruments
DAC (D/A Converters) 2.7 to 5.5V Quad Ch 16-Bit Serial Input
Data Sheet
0-1628: $6.13
1628-2000: $6.13
DAC8534IPWRG4
DAC8534IPWRG4
Texas Instruments
DAC (D/A Converters) 2.7 to 5.5V Quad Ch 16-Bit Serial Input
Data Sheet
0-1628: $6.13
1628-2000: $6.13
