Product Summary
The TLV3012AIDBVR is a push-pull output comparator. It features an uncommitted on-chip voltage reference. The TLV3012AIDBVR has 5μA(max) quiescent current, input common-mode range 200mV beyond the supply rails, and single-supply operation from 1.8V to 5.5V. The integrated 1.242V series voltage reference offers low 100ppm/℃ (max) drift, is stable with up to 10nF capacitive load, and can provide up to 0.5mA (typ) of output current. The applications of the TLV3012AIDBVR include: (1)battery-powered level detection; (2)data acquisition; (3)system monitoring; (4)oscillators; (5)sensor systems: smoke detectors, light sensors, alarms.
Parametrics
TLV3012AIDBVR absolute maximum ratings: (1)Supply Voltage: +7V; (2)Signal Input Terminals, Voltage: –0.5V to (V+) + 0.5V; Current: ±10mA; (3)Output Short-Circuit: Continuous; (4)Operating Temperature: –55℃ to +150℃; (5)Storage Temperature: –55℃ to +150℃; (6)Junction Temperature: +150℃; (7)Lead Temperature (soldering, 10s): +300℃; (8)ESD Rating (Human Body Model): 2000V.
Features
TLV3012AIDBVR features: (1)low quiescent current: 5μa (max); (2)integrated voltage reference: 1.242v; (3)input common-mode range: 200mv beyond rails; (4)voltage reference initial accuracy: 1%; (5)push-pull output: tlv3012; (6)low-supply voltage: 1.8v to 5.5v; (7)fast response time: 6μs propagation delay with 100mv overdrive (tlv3011: rpull-up = 10kω); (8)microsize packages: sot23-6 and sc70-6.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 TLV3012AIDBVR |
Texas Instruments |
Comparator ICs Nanopower 1.8V Push-Pull |
Data Sheet |
|
|
||||||||
|
TLV3012AIDBVRG4 |
Texas Instruments |
Comparator ICs Nanopower 1.8V Push-Pull |
Data Sheet |
|
|
||||||||
