Product Summary
The OPA2227U/2K5 op amp combines low noise and wide bandwidth with high precision to make it the ideal choice for applications requiring both ac and precision dc performance. The OPA2227U/2K5 is unity-gain stable and features high slew rate (2.3V/μs) and wide bandwidth (8MHz). The OPA2227U/2K5 op amp is ideal for professional audio equipment. In addition, low quiescent current and low cost make it ideal for portable applications requiring high precision. The op amp is pin-for-pin replacements for the industry standard OP-27 and OP-37 with substantial improvements across the board. The dual and quad versions are available for space savings and perchannel cost reduction. The OPA2227U/2K5 is available in DIP-8 and SO-8 packages. The device is available in DIP-14 and SO-14 packages with standard pin configurations.
Parametrics
OPA2227U/2K5 absolute maximum ratings: (1)Supply Voltage:±18V; (2)Signal Input Terminals, Voltage:(V-) –0.7V to (V+) +0.7V, Current:20mA; (3)Output Short-Circuit:Continuous; (4)Operating Temperature:–55℃ to +125℃; (5)Storage Temperature:–65℃ to +150℃; (6)Junction Temperature:150℃; (7)Lead Temperature (soldering, 10s):300℃.
Features
OPA2227U/2K5 features: (1)low noise: 3nV/√Hz; (2)wide bandwidth: OPA227: 8MHz, 2.3V/μs; OPA228: 33MHz, 10V/μs; (3)settling time: 5μs(significant improvement over OP-27); (4)high cmrr: 138dB; (5)high open-loop gain: 160dB; (6)low input bias current: 10nA max; (7)low offset voltage: 75μV max; (8)wide supply range: ±2.5V to ±18V; (9)OPA227 replaces OP-27, LT1007, MAX427; (10)OPA228 replaces OP-37, LT1037, MAX437; (11)single, dual, and quad versions.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 OPA2227U/2K5 |
Texas Instruments |
Operational Amplifiers - Op Amps High Prec Low Noise Oper Amplifier |
Data Sheet |
|
|
||||||||||
|
OPA2227U/2K5E4 |
Texas Instruments |
Operational Amplifiers - Op Amps High Prec Low Noise Oper Amplifier |
Data Sheet |
Negotiable |
|
||||||||||
|
OPA2227U/2K5G4 |
Texas Instruments |
Operational Amplifiers - Op Amps High Prec Low Noise Oper Amplifier |
Data Sheet |
|
|
||||||||||
