Product Summary
The UCC3808ADTR-2 is a low power current mode push-pull PWM. The UCC3808ADTR-2 is an enhanced version of the UCC3808 family. The significant difference is that the A versions feature an internal discharge transistor from the CS pin to ground, which is activated each clock cycle during the oscillator dead time. The feature of the UCC3808ADTR-2 discharges any filter capacitance on the CS pin during each cycle and helps minimize filter capacitor values and current sense delay.
Parametrics
UCC3808ADTR-2 absolute maximum ratings: (1)Supply voltage (IDD ≤ 10 mA): 15 V; (2)Supply current: 20 mA; (3)OUTA/OUTB source current (peak): –0.5 A; (4)OUTA/OUTB sink current (peak): 1.0 A; (5)Analog inputs (FB, CS): –0.3 V to VDD 0.3 V, not to exceed 6 V; (6)Power dissipation at TA = 25℃ (N package): 1 W; (7)Power dissipation at TA = 25℃ (D package): 650 mW; (8)Power dissipation at TA = 25℃ (PW package): 400 mW; (9)Storage temperature, Tstg: –65℃ to150℃; (10)Junction temperature, TJ: –55℃ to 150℃; (11)Lead temperature (soldering, 10 sec.): 300℃.
Features
UCC3808ADTR-2 features: (1)Dual Output Drive Stages in Push-Pull Configuration; (2)Current Sense Discharge Transistor to Improve Dynamic Response; (3)130-μA Typical Starting Current; (4)1-mA Typical Run Current; (5)Operation to 1 MHz; (6)Internal Soft Start; (7)On-Chip Error Amplifier With 2-MHz Gain Bandwidth Product; (8)On Chip VDD Clamping; (9)Output Drive Stages Capable of 500-mA Peak-Source Current, 1-A Peak-Sink Current,
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 UCC3808ADTR-2 |
Texas Instruments |
Current Mode PWM Controllers Low-Pwr Current-Mode Push-Pull PWM |
Data Sheet |
|
|
||||||||||||
|
UCC3808ADTR-2G4 |
Texas Instruments |
Current Mode PWM Controllers Low-Pwr Current-Mode Push-Pull PWM |
Data Sheet |
|
|
||||||||||||
