Product Summary

This TPS76801QPWPR is designed to have a fast transient response and be stable with 10μF low ESR capacitors. This combination provides high performance at a reasonable cost. The TPS76801QPWPR is offered in 1.5-V, 1.8-V, 2.5-V, 2.7-V, 2.8-V, 3.0-V, 3.3-V, and 5.0-V fixed-voltage versions and in an adjustable version (programmable over the range of 1.2 V to 5.5 V). Output voltage tolerance is specified as a maximum of 2% over line, load, and temperature ranges. The TPS76801QPWPR family is available in 8-pin SOIC and 20-pin PWP packages.

Parametrics

TPS76801QPWPR absolute maximum ratings: (1)Input voltage range, VI: -0.3 V to 13.5 V; (2)Voltage range at EN: -0.3 V to VI + 0.3 V; (3)Maximum PG voltage: 16.5 V; (4)Peak output current: Internally limited; (5)Continuous total power dissipation: See dissipation rating tables; (6)Output voltage, VO (OUT, FB): 7 V; (7)Operating junction temperature range, TJ: -40℃ to 125℃; (8)Storage temperature range, Tstg: -65℃ to 150℃; (9)ESD rating, HBM: 2 kV.

Features

TPS76801QPWPR features: (1)1 A Low-Dropout Voltage Regulator; (2)Available in 1.5-V, 1.8-V, 2.5-V, 2.7-V, 2.8-V, 3.0-V, 3.3-V, 5.0-V Fixed Output and Adjustable Versions; (3)Dropout Voltage Down to 230 mV at 1 A (TPS76850); (4)Ultralow 85 μA Typical Quiescent Current; (5)Fast Transient Response; (6)2% Tolerance Over Specified Conditions for Fixed-Output Versions; (7)Open Drain Power Good (See TPS767xx for Power-On Reset With 200-ms Delay Option); (8)8-Pin SOIC and 20-Pin TSSOP (PWP) Package; (9)Thermal Shutdown Protection.

Diagrams

TPS76801QPWPR Typical Application Configuration

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
TPS76801QPWPR
TPS76801QPWPR
Texas Instruments
Low Dropout (LDO) Regulators Micropower LDO Reg
Data Sheet
0-1290: $0.76
1290-2000: $0.72
2000-5000: $0.69
5000-10000: $0.67
TPS76801QPWPREP
TPS76801QPWPREP
Texas Instruments
Low Dropout (LDO) Regulators Mil Enh Fast-Trans Resp 1A LDO
Data Sheet
0-1355: $2.15
1355-2000: $2.08
TPS76801QPWPRQ1
TPS76801QPWPRQ1
Texas Instruments
Low Dropout (LDO) Regulators Auto Cat Fast-Trans- Response
Data Sheet
0-1: $1.58
1-25: $1.26
25-100: $1.01
100-250: $0.84
TPS76801QPWPRG4
TPS76801QPWPRG4
Texas Instruments
Low Dropout (LDO) Regulators Micropower LDO Reg
Data Sheet
0-1290: $0.76
1290-2000: $0.72
2000-5000: $0.69
5000-10000: $0.67
TPS76801QPWPRG4Q1
TPS76801QPWPRG4Q1
Texas Instruments
Low Dropout (LDO) Regulators Auto Cat Fast Trans Response
Data Sheet
0-1420: $0.80
1420-2000: $0.79
2000-5000: $0.78
