Product Summary
Use of the TLE2425IDR over other typical circuit solutions gives the designer increased dynamic signal range, improved signal-to-noise ratio, lower distortion, improved signal accuracy, and easier interfacing to ADCs and DACs. These benefits are the result of combining a precision micropower voltage reference and a high-performance precision operational amplifier in a single silicon chip. It is the precision and performance of these two circuit functions together that yield such dramatic system-level performance. The TLE2425IDR improves input regulation as well as output regulation and, in addition, reduces output impedance and power dissipation in a majority of virtual-ground-generation circuits. Both input regulation and load regulation exceed 12 bits of accuracy on a single 5-V system. Signal-conditioning front ends of data acquisition systems that push 12 bits and beyond can use the TLE2425IDR to eliminate a major source of system error.
Parametrics
TLE2425IDR absolute maximum ratings: (1)Continuous input voltage, VI: 40 V; (2)Output current, IO: ±80 mA; (3)Duration of short-circuit current at (or below) 25℃ (see Note 1): unlimited; (4)Continuous total power dissipation: See Dissipation Rating Table; (5)Storage temperature range, Tstg: -65℃ to 150℃; (6)Lead temperature 1,6 mm (1/16 inch) from case for 10 seconds: D package: 260℃; (7)Lead temperature 1,6 mm (1/16 inch) from case for 60 seconds: JG or LP package: 300℃.
Features
TLE2425IDR features: (1)2.5-V Virtual Ground for 5-V/GND Analog Systems; (2)High Output-Current Capability Sink or Source: 20 mA Typ; (3)Micropower Operation: 170 μA Typ; (4)Excellent Regulation Characteristics – Output Regulation, -45 μV Typ at IO = 0 to –10 mA; +15 μV Typ at IO = 0 to +10 mA; (5)– Input Regulation = 1.5 μV/V Typ; (6)Low-Impedance Output: 0.0075 Ω Typ; (7)Macromodel Included.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 TLE2425IDR |
Texas Instruments |
Voltage & Current References Prec Virtual Ground |
Data Sheet |
|
|
||||||||||||
|
TLE2425IDRG4 |
Texas Instruments |
Other Power Management Prec Virtual Ground |
Data Sheet |
|
|
||||||||||||
