Product Summary
The TL061IP is a low-power JFET-input operational amplifier. The JFET-input operational amplifier of theTL061IP is designed as low-power versions of the TL08_ series amplifiers. It features high input impedance, wide bandwidth, high slew rate, and low input offset and input bias currents. The TL061IP features the same terminal assignments. The JFET-input operational amplifier TL061IP incorporates well-matched, high-voltage JFET and bipolar transistors in an integrated circuit.
Parametrics
TL061IP absolute maximum ratings: (1)Supply voltage, VCC+: 18 V; (2)Supply voltage, VCC: -18 V; (3)Differential input voltage, VID: ±30 V; (4)Input voltage, VI: ±15 V; (5)Operating virtual junction temperature, TJ: 150 ℃; (6)Case temperature for 60 seconds FK package: 260 ℃; (7)Lead temperature 1,6 mm (1/16 inch) from case for 60 seconds: 300℃; (8)Storage temperature range, Tstg: -65 to 150 ℃.
Features
TL061IP features: (1)Very Low Power Consumption; (2)Typical Supply Current 200 μA (Per Amplifier); (3)Wide Common-Mode and Differential Voltage Ranges; (4)Low Input Bias and Offset Currents; (5)Common-Mode Input Voltage Range Includes VCC+ ; (6)Output Short-Circuit Protection; (7)High Input Impedance JFET-Input Stage; (8)Internal Frequency Compensation; (9)Latch-Up-Free Operation; (10)High Slew Rate 3.5 V/μs Typ.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 TL061IPE4 |
Texas Instruments |
Operational Amplifiers - Op Amps Low-Power JFET-Input |
Data Sheet |
|
|
||||||||||||
|
TL061IP |
Texas Instruments |
Operational Amplifiers - Op Amps Low Power JFET Input |
Data Sheet |
|
|
||||||||||||
