Product Summary

The OPA336UA/2K5G4 is a microPower CMOS operational amplifier designed for battery-powered applications. The device operates on a single supply with operation as low as 2.1V. The output is rail-to-rail and swings to within 3mV of the supplies with a 100kΩ load. The common-mode range extends to the negative supply-ideal for single-supply applications. Single, dual, and quad versions have identical specifications for maximum design flexibility. The applications of the OPA336UA/2K5G4 include battery-powered instruments, portable devices, high-impedance applications, photodiode pre-amps, precision integrators, medical instruments and test equipment.

Parametrics

OPA336UA/2K5G4 absolute maximum ratings: (1)Supply Voltage: 7.5V; (2)Signal Input Terminals, Voltage: (V–) –0.3V to (V+) +0.3V; (3)Current: 10mA; (4)Output Short-Circuit: Continuous; (5)Operating Temperature: –55 to +125℃; (6)Storage Temperature:–55 to +125℃; (7)Junction Temperature: 150℃; (8)Lead Temperature (soldering, 10s): 300℃; (9)ESD Rating:1000V.

Features

OPA336UA/2K5G4 features: (1)single-supply operation; (2)rail-to-rail output (within 3mV); (3)micropower: IQ = 20μA/Amplifier; (4)microsize packages; (5)low offset voltage: 125μV max; (6)specified from VS = 2.3V to 5.5V; (7)single, dual, and quad versions.
