Product Summary

The OPA277PA is a high precision operational amplifier. The OPA277PA precision op amps replace the industry standard OP-177. The OPA277PA offers improved noise, wider output voltage swing, and are twice as fast with half the quiescent current. Features include ultra low offset voltage and drift, low bias current, high common-mode rejection, and high power supply rejection. Single, dual, and quad versions have identical specifications for maximum design flexibility. The OPA277PA op amp operates from ±2V to ±18V supplies with excellent performance. Unlike most op amps which are specified at only one supply voltage, the OPA277PA is specified for real-world applications; a single limit applies over the ±5V to ±15V supply range.

Parametrics

OPA277PA absolute maximum ratings: (1)Supply Voltage: 36V; (2)Input Voltage: (V–) –0.7V to (V+) +0.7V; (3)Output Short-Circuit: Continuous; (4)Operating Temperature: –55℃ to +125℃; (5)Storage Temperature: –55℃ to +125℃; (6)Junction Temperature: 150℃; (7)Lead Temperature (soldering, 10s): 300℃.

Features

OPA277PA features: (1)Ultra low offset voltage: 10mV; (2)Ultra low drift: ±0.1mV/℃; (3)High open-loop gain: 134dB; (4)High common-mode rejection: 140dB; (5)High power supply rejection: 130dB; (6)Low bias current: 1nA max; (7)Wide supply range: ±2V to ±18V; (8)Low quiescent current: 800mA/amp; (9)Single, dual, and quad versions replaces OP-07, OP-77, OP-177.

Diagrams

OPA277PA Input Bias Current Cancellation

Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
OPA277PA
OPA277PA

Texas Instruments

Operational Amplifiers - Op Amps High Precision Oper Amplifier

Data Sheet

0-1: $1.15
1-10: $1.03
10-25: $0.92
25-100: $0.62
OPA277PAG4
OPA277PAG4

Texas Instruments

Operational Amplifiers - Op Amps High Precision Oper Amplifier

Data Sheet

0-1: $1.15
1-10: $1.03
10-25: $0.92
25-100: $0.62
