Product Summary
The MAX962ESA+T is a low－power, ultra－high－speed comparator with internal hysteresis. The MAX962ESA+T is optimized for single +3V or +5V operation. The input common－mode range extends 100mV Beyond－the－RailsTM, and the outputs can sink or source 4mA to within 0.52V of GND and VCC. Propagation delay is 4.5ns (5mV overdrive), while supply current is 5mA per comparator. The MAX962ESA+T has a shutdown mode in which they consume only 270μA supply current per comparator. The MAX961/MAX963 provide complementary outputs and a latch－enable feature. Latch enable allows the user to hold a valid comparator output. The MAX999 is available in a tiny SOT23－5 package. The single MAX962ESA+T is available in space－saving 8－pin uMAX packages.
Parametrics
MAX962ESA+T absolute maximum ratings: (1)Supply Voltage, VCC to GND: －0.3V to +6V; (2)All Other Pins: －0.3V to (VCC + 0.3V); (3)Duration of Output Short Circuit to GND or VCC : Continuous; (4)Supply Voltage, VCC to GND: －0.3V to +; (5)All Other Pins: －0.3V to (VCC + 0.3V); (6)Duration of Output Short Circuit to GND or VCC : Continuous.
Features
MAX962ESA+T features: (1)Ultra－Fast, 4.5ns Propagation Delay; (2)Ideal for +3V and +5V Single－Supply Applications; (3)Beyond－the－Rails Input Voltage Range; (4)Low, 5mA Supply Current (MAX997/MAX999); (5)3.5mV Internal Hysteresis for Clean Switching; (6)Output Latch (MAX961/MAX963); (7)TTL/CMOS－Compatible Outputs; (8)270uA Shutdown Current per Comparator (MAX961/MAX963/MAX964/MAX997).
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 MAX962ESA+T |
Maxim Integrated Products |
Comparator ICs Dual Comparator |
