MAX846AEEE-T

cost－saving multichemistry batterycharger system, 0.3V, 10mA, QSOP

Rated 5 Rating 5 | reviews | Write a review

Price:: US $1.35~1.51 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $1.35~1.51

PartNumber:: MAX846AEEE-T

Brand:: Maxim Integrated Products - Maxim | Pack: QSOP | D/C: 01+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. jenny's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2012-05-29

From Other Seller

Part Number:MAX846AEEE-T
US $1.35 - 1.51
2DI75D-050A

US $16.00 - 30.00 / Piece
(0) Remove
RTL8102EL

US $1.00 - 2.00 / Piece
(0) Remove
Quantity:

piece

Product Summary

The MAX846AEEE-T is a cost－saving multichemistry batterycharger system that comes in a space－saving 16－pin QSOP. This integrated system allows different battery chemistries (Li－Ion, NiMH or NiCd cells) to be charged using one circuit. In its simplest application, the MAX846AEEE-T is a standalone, current－limited float voltage source that charges Li－Ion cells. It can also be paired up with a low－cost microcontroller (μC) to build a universal charger capable of charging Li－Ion, NiMH, and NiCd cells. An internal 0.5%－accurate reference allows safe charging of Li－Ion cells that require tight voltage accuracy. The MAX846AEEE-T voltage－ and current－regulation loops used to control a low－cost external PNP transistor (or P－channel MOSFET) are independent of each other, allowing more flexibility in the charging algorithms.

Parametrics

MAX846AEEE-T absolute maximum ratings: (1)DCIN, DRV, CS+, CS－, BATT to GND: －0.3V, +21V; (2)PGND to GND: ±0.3V; (3)VL to GND: －0.3V, 7V; (4)IPWROK: 10mA; (5)PWROK, ISET, CCI, CCV, OFFV, VSET, CELL2, ON to GND : －0.3V, VL + 0.3V; (6)CS+ to CS－: ±0.3V; (7)VL Short to GND: Continuous; (8)IDRV: 100mA.

Features

MAX846AEEE-T features: (1)Space－Saving 16－Pin QSOP; (2)Charging－Current－Monitor Output; (3)<1uA Battery Drain when Off; (4)Multichemistry Charger System (Li－Ion, NiMH, NiCd); (5)Independent Voltage and Current Loops; (6)±0.5% Internal Reference for Li－Ion Cells.
